Synths ⇝ Yamaha ⇝ Yamaha EX5R

The EX5R is a rackmount version of the 76-key Yamaha EX5. It is also available in a stripped-down 61-key version as the Yamaha EX7.

Specifications

Year Released: 1998

Polyphony: 128 notes

Multitimbral: 16 parts

Preset Patches: 256

User Patches: 256

User Performances: 128

ROM: 16MB

Sequencer Memory: 30,000 notes

Sequencer Resolution: 480 PPQN

Effects: 108 effects - 79 insertion, 17 chorus, 12 reverb

Arpeggiator: 50 preset patterns, 50 user patterns

Screen: 240 x 64 pixel backlit LCD

Power Consumption: 32 watts

Dimensions: 480 mm x 397 mm x 138 mm

Weight: 9.8 kg

This is a 3-space rack unit.

User Demo Videos

Rating

Sound Samples

WAV samples are available on freewavesamples.com.

File Downloads

Yamaha EX5 and EX7 Manual

Yamaha EX5 Data List
